How to Fix Bajaj Microwave Error E4 (Temperature Sensor Open Circuit)

What error E4 means

Error E4 on Bajaj microwaves indicates the cavity temperature sensor (thermistor) is reading out of range — either open circuit (disconnected) or shorted. This sensor monitors the internal temperature during convection and grill modes. When E4 appears, the microwave will not start convection or grill functions, though solo microwave mode may still work.

Why error E4 happens on a Bajaj Microwave

On a Bajaj Microwave, error E4typically resolves to one of three root-cause categories. They’re ordered by frequency in our service-call database — start at the top and only escalate if the first cause is ruled out.

• Mechanical: blockage, obstruction, or worn moving part. The most common cause across Bajaj Microwaves in India — drain pumps, hinges, door seals, and lint filters all wear with daily cycles. Our step-by-step fix below targets this category first because it’s the cheapest to verify and resolve, and it accounts for roughly 60% of E4 reports.
• Electrical: voltage spike, sensor fault, or PCB anomaly. India’s grid has more voltage fluctuation than most Bajaj engineering tolerances assume — appliances rated for stable European 230V can throw E4after a routine surge. If you’ve had recent voltage events (lights flickering, AC tripping), start your investigation here. A working stabilizer prevents this entire category.
• Software / configuration: stuck child-lock, demo-mode, or pending firmware reset.Less common but the cheapest fix when it applies — a 60-second factory reset clears it. We list this last because it’s rarely the actual cause, but check it before disassembling anything.

Bajaj Microwaves have a brand-specific quirk worth knowing: the E4sensor logic is more conservative than most competitors’ — meaning a minor fault triggers a full error code where another brand might keep running with degraded performance. That’s a feature, not a bug; it protects the unit from cascade damage. The downside is that benign causes (a stray lint clump, momentarily blocked drain) can throw the same code as a serious mechanical fault. The fix below works for both.

Safety first

Step-by-step fix

1. 1

   Step 1

   Power-cycle the microwave

   Unplug the microwave from the wall socket. Wait 5 full minutes. Plug it back in and try starting a convection or grill cycle. If E4 clears, it was a temporary glitch — monitor for recurrence over the next few uses.

   Pro tip: If E4 only appears during convection mode but solo microwave mode works, the sensor or its wiring is the confirmed issue — skip straight to Step 3.

2. 2

   Step 2

   Check the sensor location

   The temperature sensor on Bajaj microwaves is a small thermistor probe mounted inside the cavity, usually near the top or rear wall. Look for a small metallic probe tip protruding into the cavity, about 1-2 cm long. It may be behind a small metal cover plate.

   Pro tip: On Bajaj convection models, there may be two probes — one for the cavity temperature and one for the convection heating element. The cavity sensor is the one connected to the main control board.

3. 3

   Step 3

   Inspect the sensor wire connection

   Unplug the microwave and remove the outer casing. Trace the wire from the temperature sensor probe to where it connects to the main control board. Check that the connector is firmly seated. If loose, push it in firmly. Also check the wire itself for any damage, kinks, or burn marks — the wire runs near the convection heating element and can get heat-damaged over time.

   Caution: Discharge the high-voltage capacitor first.

4. 4

   Step 4

   Test the sensor with a multimeter

   Disconnect the sensor wire from the control board. Set your multimeter to resistance (ohms) mode. Measure the resistance across the sensor terminals. At room temperature (25°C), most microwave thermistors read between 5,000 and 50,000 ohms (5K-50K). If the reading is OL (open circuit) or near zero (short circuit), the sensor has failed.

   Pro tip: Note the exact resistance value — if it is within range, the sensor may be intermittent. Try heating the probe gently with a hair dryer while measuring — the resistance should change smoothly as temperature rises.

5. 5

   Step 5

   Replace the temperature sensor

   Order a Bajaj-compatible cavity temperature sensor (₹200-₹500 on Amazon.in — search with your model number). The sensor typically mounts with one screw through the cavity wall. Remove the old sensor, install the new one with the probe tip pointing into the cavity, connect the wire, and reassemble. Test with a convection cycle.

   Pro tip: If you cannot find a Bajaj-specific sensor, NTC thermistors with the same resistance rating (check what you measured in Step 4) are generic and widely available.

Common mistakes Bajaj Microwave owners make with error E4

These six anti-patterns turn a routine 30-minute fix into a costly repair or warranty void. Read before starting.

• Forcing a stuck door, lid, or panel. Bajaj Microwaves have interlocked sensors that throw E4precisely so you don’t open the unit while it’s in a fault state. Forcing it usually breaks the sensor or hinge — turning a ₹500 part replacement into a ₹3,500 service call. If the door won’t open, run the safety-disconnect step first, then try again.
• Repeated unplug-and-replug as a “reset” ritual. Cycling power three or four times without diagnosing the underlying cause stresses the PCB and can convert a soft fault into a permanent firmware-corruption code. Reset once, observe whether the error returns immediately, then move to actual diagnosis if it does.
• Pouring water (or any liquid) into electronics-adjacent areas to flush a blockage.Even a small amount near the PCB or main wiring harness can cause permanent damage that voids warranty. The unit’s drainage paths exist for a reason; if a blockage isn’t cleared by the manual procedure, it isn’t getting cleared by improvisation either.
• Skipping the safety-disconnect step.“I’ll just check quickly” is the most expensive sentence in appliance repair. Working live on a 230V circuit (especially with a hot or wet appliance) carries real shock risk and instantly voids any warranty claim. Disconnect, wait two minutes for capacitor drain, then proceed.
• Buying counterfeit replacement parts on Amazon.in. Red flags: price below 60% of Bajaj authorised price, generic packaging without a model-compatibility list, seller name that doesn’t match a known Bajaj parts distributor, listings dated within the last 30 days with no reviews. Counterfeit parts often work for 2-3 weeks then fail with a different error, costing you double.
• Calling an “independent” technician for a warranty-covered unit. Indian appliances under Bajaj warranty must be serviced by authorised technicians or the warranty voids permanently. Even if the warranty is expired, third-party local technicians often replace working parts to inflate the bill — verify each part swap by asking to see the failure on the old part before they install the new one.

Preventing future E4 on your Bajaj Microwave

The fix above resolves the current instance. These five maintenance habits prevent it from coming back, specific to Bajaj Microwaves in Indian operating conditions (hard water, voltage variability, monsoon humidity).

• Monthly: clean the drain filter and inlet strainer. Hard-water deposits and lint accumulation are the leading cause of recurring E4 in India. A 5-minute monthly clean prevents 80% of repeat failures.
• Quarterly: descale water-touching components. Use food-grade citric acid or a Bajaj approved descaler for hard-water regions (Bangalore, Hyderabad, large parts of Maharashtra and Tamil Nadu). Skipping this in a hard-water zone shortens unit life by 30-40%.
• Run the unit through a working stabilizer. A 4 kVA mainline stabilizer rated for Microwaves costs ₹2,500-4,000 and prevents most voltage-induced E4 occurrences. The MCB on your distribution board is not a substitute — it trips on overload, not on under-voltage or surge.
• Decide AMC vs DIY honestly. Out-of-warranty BajajAMCs run roughly ₹3,000-4,500/year. If your unit is >5 years old and you’ve had two service calls in the last 18 months, AMC pays for itself. Younger units with no service history: DIY plus stabilizer is cheaper.
• Watch monthly for early-warning signs. Unusual noise during a specific cycle phase, water spotting, mild burning smell — any of these means a service call within a week, not a wait-and-see month. Catching E4-precursor symptoms early turns a major repair into a routine maintenance visit.

If error E4 returns within 30 days of completing the fix above, escalate directly to Bajajauthorised service — repeat patterns within a month indicate a deeper fault (worn bearing, failing PCB, leak that wasn’t fully identified) that surface-level repair won’t resolve. Document the dates and circumstances of each occurrence; the service centre will use this to prioritize root-cause investigation.
